| Frequency response |
50 Hz to 20 kHz (+1/‑3 dB @ ‑10 dB ref. rated output) |
| Distortion |
<1% @ rated output power, 1 kHz |
| Low Control |
Max -12/+12 dB (frequency is setting dependent) |
| Hi Control |
Max -12/+12 dB (frequency is setting dependent) |
| RJ-45 input |
2 x |
| Call station input |
For PLE-2CS(MM) |
| Wall panel input |
For PLE-WP3S2Z |
| Mic/line input |
6 x |
| Input 1 (Push-to-talk contact with ducking functionality) |
5-pin Euro style, balanced, phantom3-pin XLR, balanced, phantom |
| Input 2-6 (VOX with ducking functionality on input 2) |
3-pin XLR, balanced, phantom |
| Sensitivity |
1 mV (mic); 1 V (line) |
| Impedance |
>1 kohm (mic); >5 kohm (line) |
| S/N (flat at max volume) |
63 dB |
| S/N (flat at min volume/muted) |
>5 dB |
| Dynamic range |
93 dB |
| S/N (flat at max volume) |
>63 dB (mic); >70 dB (line) |
| S/N (flat at min volume/muted) |
>75 dB |
| CMRR (mic) |
>40 dB (50 Hz to 20 kHz) |
| Headroom |
>17 dB |
| Speech filter |
-3 dB @ 315 Hz, high-pass, 6 dB/oct |
| Phantom power supply |
16 V via 1.2 kohm (mic) |
| Speech filter |
-3 dB @ 315 Hz, high-pass, 6 dB/oct |
| VOX (input 1 & 2) |
attack time 150 ms; release time 2 s |
| Music inputs |
3x |
| Connector |
Cinch, stereo converted to mono |
| Sensitivity |
300 mV |
| Impedance |
22 kohm |
| S/N (flat at max volume) |
>70 dB |
| S/N (flat at min volume/muted) |
>75 dB |
| Headroom |
>25 dB |
| Emergency / telephone |
1 x |
| Connector |
7-pin, Euro style pluggable screw terminal |
| Sensitivity tel |
1 V maximum |
| Sensitivity 100V |
100 V maximum |
| Impedance |
>10 kohm |
| S/N (flat at max volume) |
>65 dB |
| VOX |
threshold 50 mV; attack time 150 ms; release time 2 s |
| Insert |
1 x |
| Connector |
Cinch |
| Nominal level |
1 V |
| Impedance |
>10 kohm |
| Master/music output |
1 x |
| Connector |
3-pin XLR, balanced |
| Nominal level |
1 V |
| Impedance |
<100 ohm |
