• 90° x 50° coverage for even and smooth response on and off axis
• Dual-angle pole socket for applications requiring tripod mounting
• Heavy Duty 16 gauge protective screen backed steel grille
• Tough DuraFlex™ enclosure finish
• Utilizes twelve M10 suspension points for safe deployment in light duty installations.
• SonicGuard™ protects the highfrequency driver from excess power without interrupting the performance.

Specifications

• Frequency Range (-10dB):       50 Hz – 20 kHz
• Frequency Response (±3 dB)  :     62 Hz – 19 kHz
• Coverage Pattern :        90° x 50° nominal
• System Sensitivity :       95 dB SPL (1w@1m)
• Power Rating, Pink Noise :      300 W / 600 W / 1200 W(Continuous/Program/Peak)
• Maximum SPL (1m):   126 dB SPL peak
• Nominal Impedance :   8 ohms
• Dimensions (H x W x D): 574 mm x 353 mm x 399 mm (22.6 in x 13.9 in x 15.7 in)
• Net Weight :   16 kg (35 lbs.)
• Inputs:   Parallel Neutrik® Speakon® NL-2 / ¼” phone combo jacks
• Enclosure  :     Duraflex coated plywood
