เครื่องรับ Wireless Receiver ยี่ห้อ Audio-Technica รุ่น ATW-R1100EX
The Audio-Technica ATW-1100 System 10 is a tabletop digital wireless receiver compatible with all System 10 transmitters. The portable receiver is well suited for quick setup in educational facilities, conference rooms, small venues, and houses of worship as well as web broadcast studios.
Features
- For Small Venues and Conference Rooms
- Single-Channel, Portable Tabletop Design
- Triple-Diversity Reception
- Fixed Antennas
- Expandable to 8 Mic Channels/100′ Range
Specifications
System
| Wireless Transmission | Digital 2.4 GHz |
| Diversity | Frequency, Time & Space Diversity |
| RF Frequency Band | 2400 to 2483.5 MHz |
| Max Operating Range | 100′ / 30.5 m (Line of Sight) |
| Max Systems per Setup | 8 |
Receiver
| Form Factor | Tabletop |
| Antenna | 2 x External, Fixed (Front-Mount) |
| Number of Audio Channels | 1 |
| Audio I/O | 1 x XLR 3-Pin Male Balanced Output (Lockable) 1 x 1/4″ TS Female Unbalanced Output |
| Audio Output Level | XLR Output: 0 dBV (Balanced) 1/4″ Output: +6 dBV (Unbalanced) |
| Frequency Response | 20 Hz to 20 kHz (Dependent on Mic) |
| Power Requirements | AC/DC Power Adapter |
| AC/DC Power Adapter | 12 VDC at 0.5 A (Included) |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Display & Indicators | 1 x LED (Channel, Peak, Sync) |
| Housing | Plastic |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Dimensions | 7.5 x 1.8 x 5.1″ / 190 x 46.2 x 128.5 mm |
| Weight | 10.2 oz / 290 g |
