Panel Size

3-Chip DLP 24mm (0.96″)

Resolution

WUXGA (1920 x 1200)

Light Output (Brightness) ANSI Lumens

13000 (Normal) , 10060 (Eco)

Contrast Ratio

2000:1

Lamp Life (Hours)

2000 (Normal) , 2500 (Eco)

Lens

Interchangeable, not included

Lens Zoom

Powered Zoom

Lens Focus

Powered Focus

Throw Distance

4 – 24m(ML-K04)

Distance to Width Ratio/ Throw Ratio (:1)

1.87 (Wide) –2.56 (Tele)( ML-K04)

Diagonal Display Size

80– 600″

Digital Keystone Correction

Horizontal ± 35°, Vertical ± 20°

Digital Input

HDMI x 2, DVI-D x 1, SDI/HDSDI/3G BNC x 1

Analogue Input

15 pin Mini D-Sub x 1, 3 RCA Jack x 1, 5 BNC x 1

Video Output

SDI/HDSDI/3G BNC x 1

RS-232C Control

1 x 9-pin D-Sub

Wireless LAN

No

Wired LAN

Yes

USB Type A

Not supported

USB Type B

No

Power Supply

AC 100 – 130V, AC 200 – 240V (50/60Hz)

Operating Power Consumption

1250W

Standby Power Consumption

Less than 3W

Weight

34kg (excluding lens)

Dimensions (W x H x D) (Without feet)

500 x 633 x 270mm (excluding feet and extrusions)

Noise

46dB (Normal) , 42dB (Eco)

Filter Life (Hours)

10000

Computer

IBM Compatible VGA, SVGA, XGA, WXGA/WXGA+/ SXGA/SXGA+/WSXGA+/UXGA/WUXGA, MAC16″

Video

525i (480i), 525p (480p), 625i (576i), 1125i (1080i@50/60), 750p (720p@50/60), 1125p (1080p@50/60)

Supplied Accessories

Power Cable (2.5m) x1, IR Remote Control Unit x1, AA Batteries x2, RS232C Cable (Cross, Male to Male), EAC Document x1, Multi-lingual User Manual (CD–ROM) x1, Multi-lingual User Manual (Printed) x1

Optional Accessories

Optional Lenses: Ultra-short-Throw FL-K01, Short-throw FL-K02, Short-throw FL-K03, Standard-throw ML-K04, Long-throw LL-K05, Ultra-Long throw UL-K06

Remote Control

HL03051

Replacement Lamp / Filter

DT01591, MU08321, MU08421

Projector/ Lamp Warranty

3 years / 6 months (for education and extended warranties please contact your local dealer.)
