| Amplifier Gain |
32 dB |
| Analog Inputs |
2, electronically balanced, Phoenix-type |
| Audio Network |
No |
| CAN Bus Interface |
Optional (RCM-810 card) |
| Continuous Rated Power (1 kHz, THD 1%) 2Ω |
1800 Watts |
| Continuous Rated Power (1 kHz, THD 1%) 4Ω |
1200 Watts |
| Continuous Rated Power (1 kHz, THD 1%) 8Ω |
750 Watts |
| Continuous Rated Power (20-20 kHz,THD<0,2%) 4Ω |
1100 Watts |
| Continuous Rated Power (20-20 kHz,THD<0,2%) 8Ω |
550 Watts |
| Cooling |
Front-to-Rear, 3-stage-fans |
| Crossover Type |
Modular |
| DIM 30 |
0.05 % |
| Electronics Type |
Amplifier |
| Frequency Response |
10 Hz – 40 kHz ±1 dB |
| Impedance |
2/4/8 Ω |
| Input Impedance (Balanced) |
20 kΩ |
| Input Sensitivity |
+6.6 dBu (1.66 Vrms) |
| Intermodulation Distortion (SMPTE) |
0.1 % |
| Mains Voltage |
240 V, 230 V, 120 V or 100 V; 50 Hz – 60 Hz (factory configured) |
| Maximum Bridged Output 4Ω |
3600 Watts |
| Maximum Bridged Output 8Ω |
2400 Watts |
| Maximum Input Voltage |
+21 dBu (8.69 Vrms) |
| Network Control (IRIS-Net) |
Optional (RCM-810 card) |
| Slew Rate |
30 V/µs |
| Topology |
Class-H |
| Total Harmonic Distortion |
0.03 % |
| Variable Load Drive (VLD) |
No |
| Height |
2RU 88.1 mm (3.47“) |
| Width |
482.6 mm (19“) |
| Depth |
421.5 mm (16.59“) |
| Weight Net |
17.7 kg (39.02 lbs) |
