• 10” high efficiency woofer design
• 1” polymer diaphragm compression driver
• Enclosure constructed of 15 mm plywood with rugged durable finish
• 100° × 70° coverage pattern for even and smooth response on and off axis
• Heavy duty powder-coated 1.5mm steel grille of elegant design for driver protection and sleek professional appearance
• Precision engineered crossover for optimal driver integration
• Rotatable JBL COMMERCIAL logo for both horizontal and vertical applications
• Ideal for installations with limited ceiling height
• White (-WH) color available upon request
• Sound reinforcement for restaurants, canteens or dining halls, cafés, conference rooms, halls, school rooms, etc.
• High-performance satellite speaker for use with subwoofers

Specifications

• System Type:     10”, 2-way, bass-reflex
• Frequency Range (-10 dB):      50 Hz – 20 kHz
• Frequency Response (±3 dB):   85 Hz – 18 kHz
• System Sensitivity (1w @ 1m):     95 dB
• Nominal impedance:      8 Ω
• Maximum SPL (1m):        120 dB continuous average (126 dB peak)
• Power Rating (Continuous/Program/Peak):   300 W/600 W/1200 W
• Coverage:     100° × 70° (H × V)
• Low-Frequency Diver:    1 x 10” woofer
• Hight-Frequency Diver: 1 x 2414H-C tweeter
• Enclosure:   Trapezoid, 15 mm plywood
• Suspension:     15 × M10 threaded suspension points
• Exterior color:    Textured paint, black. White (-WH) available upon request.
• Net cover:    Powder coated 1.5mm perforated cold rolled steel
• Input Connector:   Dual NL4MP Neutrik Speakon® in parallel for loop-through
• Dimensions (H × W × D) 535 mm × 310 mm × 329 mm (21.0 in × 12.2 in × 13.0 in)
• Weight 13.5 kg (29.8 lbs)
