5-Port Desktop Fast Ethernet Switch ยี่ห้อ ZYXEL รุ่น ES-105A v3
The Zyxel ES-105A v3, a five port desktop switch with plug-and-play design, can easily connect devices including PCs, network storage devices and print servers to your home network. The ES-105A v3 offers advanced High Priority ports to boost performance and user experience for Internet surfing, online gaming, multimedia or any application you prefer with prioritized bandwidth.
Compact, sturdy design with wall-mount alternative
The Zyxel ES-105A v3 fits any working environment. The stylish, compact metal housing with wall-mount installation design provides more flexibility for wired home networks. The affordable, reliable series comes with five ports to meet home network expansion needs.
Optimal bandwidth for media traffics through high priority ports
The Zyxel ES-105A v3 v3 comes with two high priority ports. With the port-based QoS feature, the ES-105A v3 provides considerably enhanced download quality. Users can experience better performance for Internet surfing, online gaming and multimedia streaming through prioritized bandwidth settings. The ES-105A v3 features increased buffer memory to maintain smooth network transmission while the switch is handling heavy loads.
Easy to connect multiple devices
The Zyxel ES-105A v3 is designed to boost your home network with better performance and efficiency. With the N-way auto-negotiation function, the ES-105A v3 connects to network devices with the highest possible speed and activates full-duplex mode automatically, while the store-and-forward service offers low latency and error-free packet delivery.
Energy Saving Product
Compliant with the IEEE 802.3az Energy Efficient Ethernet standard, the ES-105A v3 provides power-saving benefits without compromising performance.
- Standard
- IEEE 802.3 10BASE-T Ethernet
- IEEE 802.3u 100BASE-TX Fast Ethernet
- IEEE 802.3 Nway auto-negotiation
- IEEE 802.3x full duplex operation and flow control
- IEEE 802.3az Energy Efficient Ethernet
- Performance
- Data transfer rate (half duplex/full duplex):
- Ethernet: 10/20 Mbps
- Fast Ethernet: 100/200 Mbps
- MAC address table: 1 K
- Memory buffer: 56 KB
- Switching fabric (non-blocking): 1.0 Gbps
- Data transfer rate (half duplex/full duplex):
- Features
- Auto-MDI/MDIX in all ports
- Transmission method: Store-and-forward architecture
- Port-based QoS support
- Interface
- Five 10/100 Mbps Ethernet ports
- QoS Ports
- Two high-priority QoS ports
- LED Indicator
- PWR: Power
- Per port: Link/Activity
- Power Supply
- Input: 100 to 240 V AC, 50/60 Hz
- Output: 5 V DC, 1 A
- Power consumption (DC side): 0.92 watt max.
- Item dimensions (WxDxH): 121 x 75 x 26 mm (4.8″ x 3.0″ x 1.0″)
- Item weight: 224 g (0.49 lb.)
- Packing dimensions (WxDxH): 127 x 82 x 95 mm (5.0″ x 3.2″ x 3.7″)
- Packing weight: 373.5 g (0.83 lb.)
- Operating Environment
- Temperature: 0°C to 40°C (32°F to 104°F)
- Humidity: 10% to 90% (Non-condensing)
- Storage Environment
- Temperature: -40°C to 70°C (-40°F to 158°F)
- Humidity: 10% to 95% (Non-condensing)
