• HIGH-PERFORMANCE EV-ENGINEERED 8” TRANSDUCER WITH HIGH-EFFICIENCY MULTI-MODE AUDIO CROSSOVER NETWORK.
• COMPACT, HIGH-DENSITY WOOD ENCLOSURE WITH PORT FOR EXTENDED BASS RESPONSE, SECURE SNAPON SPEAKER GRILLE, AND QUICK-MOUNT SLIDE-ON BRACKET SYSTEM.
• EASY-ACCESS SIGNAL CONNECTIONS WITH PHOENIX-STYLE CONNECTORS FOR QUICK WIRING, USER-FRIENDLY MODE SELECTOR FOR STEREO OR MONO OPERATION, AND EASY-TAP SELECTOR DIAL (SUPPORTS 4/8 OHM INPUTS OR UP TO 100 W / 70/100 V AUDIO CONNECTIONS).

SPECIFICATIONS

• Frequency Range (-10 dB):        42 Hz – 300kHz
• Max. SPL/1m (calc)²:    114dB
• Connector Type : Phoenix (2-pin)
• Enclosure Material:     Wood (MDF)
• Sensitivity 1 W/1 m:     88dB
• Height: 400mm (15.75″)
• Width:  400mm (15.75″)
• Depth:  230mm (9.06″)
• Weight Net:       12.05kg (26.57 lbs)
• Shipping Weight:     18.26kg (40.26 lbs)
• Transformer Taps (Transformer Version Only):   100 W, 50 W, 25 W, 12.5 W
• Impedance:        Dual 8Ω / monoΩ
• Power Handling (Continuous / Peak):      200W
• Coverage, Voice :      Omnidirectional
• Coverage, Music:      Omnidirectional
• Transducer size :200
• Bracket Adjustment Range:    Fixed
• Included Accessories:     Wall bracket, hex wrench
