Condenser Lavalier Microphones ยี่ห้อ TOA รุ่น FS-7000RM
The FS-7000RM Remote Microphone is used solely for making general-purpose announcements in the FS-7000 Series Voice Evacuation System. It can broadcast announcements to 10 different individual zones in addition to simultaneous all-zone calls.
Specification
| Power Source | 24 V DC (operating range: 20 – 30 V DC) (supplied from RJ45 connector or power input jack) Usable power input plug: 5.5 mm outer diameter, 2.1 mm inner diameter, and 9.5 mm long. |
|---|---|
| Current Consumption | 90 mA |
| Output | 0 dB*, 600 Ω, balanced, RJ45 connector |
| External Microphone Input | -40 dB*, 2.2 kΩ, unbalanced, mini jack, phantom powering |
| Distortion | Under 1% |
| Frequency Response | 100 – 20,000 Hz |
| S/N Ratio | Over 60 dB |
| Output Control | 10 individual zones + all-zone call or 10 group zones + all-zone call (when optional FS-7000GM is connected) (individual zones expandable to up to 50 zones using optional FS-7010RM) |
| Operating Section | All-zone selection key, Chime key, Broadcast reset key, zone selection keys, Talk key |
| Display Section | Power indicator, Fault indicator, Busy indicator, All-zone call indicator, Zone indicators |
| Operating Temperature | 0℃ to +40℃ |
| Operating Humidity | Under 90% RH (no condensation) |
| Finish | ABS resin, blueish gray |
| Dimensions | 190 (W) × 76.5 (H) × 215 (D) mm (gooseneck microphone excluded) |
| Weight | 900 g |
| Accessory | Connection cable (3 m) …1 |
