| Model |
75M5A |
| Size |
75” |
| Display |
| Backlight Type |
D-LED |
| Resolution |
3840*2160(UHD) |
| Brightness |
400Cd/M2 |
| Contrast Ratio |
1200:1 |
| Response Time |
8Ms |
| Pixel Pitch |
0.4296mm*0.4296mm |
| Frame Rate |
60Hz |
| Viewing Angle |
178*(H) / 178”(V) |
| Color saturation (x%NTSC) |
72% |
| Visible Area |
1649.664mm*927.936mm |
| Chromaticiy |
1.07B(10bit) |
| Life Time |
30,000hrs |
| System Properties |
| System Version |
Android 8.0 (Windows Is Optional) |
| CPU |
MSD8386 |
| CPU Working Frequency |
1.5GHz |
| CPU core |
Four |
| GPU |
Mali-G51 |
| (RAM) |
3GB |
| (ROM) |
64GB Standard |
| Power |
| Voltage |
100V – 240V/AC,50/60Hz |
| Maximum Power (Without OPS) |
300W |
| Standby Power |
<0.5W |
| Power (AC) Input |
1 |
| Touch Parameters |
| Touch Screen |
Touch Type: Infrared Touch Frame: Glass Type: Response Time: <8ms: Touch Accuracy: 1mm |
| Camera |
Pixel: 1,300w |
| Microphone |
Line 8-Array Microphoe |
| Function |
| Sound Power |
10W*2 |
| NFC |
Support |
| Bluetooth |
Support |
| Display Interface |
| Interface |
HAMI-IN 2, DP-IN 1, OPS (OPS is optional) *1, LAN network port*2, type-C *1, Android USB *2, Public USB *2, Touch-USB *1, Pc-audio IN *1, HDMI-OUT *1, S/PDIF *1, Audio-OUT *1, RS232-IN*1 |
| Structure |
| Net Weight |
50Kg+1.5Kg |
| Gross Weight |
70Kg+1.5Kg (Heavy Carton) |
| Bare Machine Dimensions (L*W*H) |
1722.41mm*87.08mm*1022.15mm |
| Package Size (L*W*H) |
1,880mm*280mm*1,160mm (Heavy Carton) |
| VESA |
4-M8 screw hole 800mm*400mm |
| Shell Material (Face Frame/Rear Shell) |
Aluminum profile / sheet metal |
| Shell Color (Face Frame/Rear Shell) |
Dark tarnish / black |
| Computer Module (Optional) |
| 15,OPS(Optional) |
Intel*CoreTMI5 8400 Processor, RAM: 8GB + SSD: 128GB |
| Packing List |
| List |
Accessory List*1, Smart Pen + Receiver*1, Smart Pan Charging Ire*1, Cable*1, Writing Pen *1, Double-End Writing Pen*1, Screen Mirroring Device*1, Remote Control*1, Battery*2, Expansion Screw *8, Instruction Manua USB Flash Disk *1, Instruction Manua *1, Certificate Of Quality / Warranty Card*1, 3m Power Cord*1; |
