SWITCH ยี่ห้อ ARUBA รุ่น JY678A
- Device Type Radio access point
- Form Factor External – indoor
- Data Link Protocol IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
- Frequency Band 2.4 GHz, 5 GHz
- Performance Concurrent data rate (5 GHz): 867 Mbps ¦ Concurrent data rate (2.4 GHz): 400 Mbps
- Capacity Wireless clients per Wi-Fi radio: 255 ¦ BSSIDs per radio: 16
- Included Accessories Single-gang wall-box
- Dimensions (WxDxH) 15 cm x 8.6 cm x 4 cm
- Weight 310 g
| SKU | JY678A |
| Brand | Aruba |
| Model | [JY678A] Access Point “Aruba” AP-303H (RW) Unified AP |
| Ports | Uplink: 10/100/1000BASE-T Ethernet (RJ-45, back), Local: 10/100/1000BASE-T Ethernet (RJ-45, bottom), Passive pass-through interface (two RJ-45, back and bottom) |
| Wi-Fi Radio Specifications | a maximum concurrent data rate of 867Mbps in the 5GHz band and 300Mbps in the 2.4GHz band |
| Wi-Fi Antennas | Two integrated dual-band moderately directional antennas for 2×2 MIMO with maximum individual antenna gain of 4.2dBi in 2.4GHz and 5.6dBi in 5GHz. Built-in antennas are optimized for vertical orientation of the AP |
| Dimension | 86mm (W) x 40mm (D) x 150mm (H) |
| Weight | 350g |
| Power sources and consumption | Maximum (worst-case) power consumption: 9.7W |
| Mounting | The AP ships with a mounting plate to attach the AP to a single-gang wall-box (most international variations covered). A security screw (T8H) is provided to ensure that the AP cannot (easily) be removed from its mount without a specialized tool |
| Mode | Controller-managed mode, Aruba Instant mode,Spectrum analysis, Hybrid AP, Air monitor (AM) |
| Warranty | Aruba Limited Lifetime Warranty |
