48-Port PoE Switch ยี่ห้อ Ruijie รุ่น RG-S5300-48GT4XS-E
|
Product Specification |
|
|
Overview |
Ruijie RG-S5300-48GT4XS-E L3-Managed Switch 48 Port, 4 Port SFP+ ,รองรับ VSU, IPv4/IPv6 Dual-stack Multi-layer Switching, Dynamic Routing RIP, OSPF, IS-IS, BGP |
| Fixed Ports | 48 x 10/100/1000Mbps adaptive electrical ports, 2 x 1G SFP ports, 2 x 1G/10G SFP+ ports (the default rate is 1Gbps) (Note: 10G uplink port activation software license needs to purchase separately) |
| Switching Capacity | 432 G/4.32 Tbps |
| Packet Forwarding Rate | 144 Mpps/166 Mpps |
| MAC Address | 32K |
| ARP Table | 4K |
| Routing Table Size (IPv4/IPv6) | 8K (IPv4/IPv6) |
| ACL Entries | In: 3,500 Out: 1,500 |
| 802.1Q VLAN | The following are supported: 4K 802.1Q VLAN Port-based VLAN MAC-based VLAN Private VLAN Voice VLAN GVRP |
| QinQ | Basic QinQ Flexible QinQ |
| ACL | The following are supported: Standard IP ACLs (IP-based hardware ACLs) Extended IP ACLs (hardware ACLs based on IP addresses or TCP/UDP port IDs) MAC-based extended ACLs (hardware ACLs based on source MAC addresses, destination MAC addresses, and optional Ethernet type) Time-based ACLs Expert-level ACLs (hardware ACLs based on flexible combinations of the VLAN ID, Ethernet type, MAC address, IP address, TCP/UDP port ID, protocol type, and time) ACL 80 IPv6 ACLs Global ACLs ACL redirection |
| QoS | The following are supported: Port traffic identification Port traffic rate limiting 802.1p/DSCP/ToS traffic classification Eight priority queues per port SP, WRR, SP+WRR, RED/WRED queue scheduling mechanisms |
| Mirror | One-to-one mirroring, many-to-one mirroring, and one-to-many mirroring RSPAN Flow-based local and remote mirroring |
| DHCP | The following are supported: DHCP server DHCP client DHCP snooping DHCP relay IPv6 DHCP snooping IPv6 DHCP client IPv6 DHCP relay |
| Multiple Spanning Tree Protocol (MSTP) Instances | 65 |
| Maximum Aggregation Port (AP) | 128 |
| Security Features | The following are supported: 3-tuple binding (IP address, MAC address, and port) 3-tuple binding (IPv6 address, MAC address, and port) Filtering of invalid MAC addresses Port- and MAC-based 802.1x authentication MAB authentication Portal authentication and Portal 2.0 authentication ARP-check DAI ARP packet rate limiting |
| Security
Features |
Gateway ARP spoofing prevention Broadcast storm suppression Hierarchical management of administrators and password protection RADIUS and TACACS+ AAA (IPv4/IPv6) for device login management SSH and SSH V2.0 BPDU guard IP source guard CPP, and NFPP Port protection |
| ERPS | G.8032 v1/v2, Sing-ring, Tangent-ring, Intersecting-ring, Load balancing, compatible with products of this protocol. |
| PoE | The following are supported: IEEE 802.3af and 802.3at power supply standards Automatic and energy saving power supply management mode Uninterrupted power supply in hot start mode Scheduled powering on /off PoE ports on the basis of time policy Port priority Note: Only RG-S5300-24GT2SFP2XS-P-E and RG-S5300-24GT4XS-P-E support the PoE function. |
| IP Routing | The following are supported: IPv4/IPv6 static routing RIP, RIPng, OSPFv2, OSPFv3, BGP, and ISIS Routing policy |
| IPv6 Basic Protocol | IPv6 addressing, Neighbor Discovery (ND), ICMPv6, IPv6 ping, IPv6 Tracert, and IPv6 multicast |
| VSU Features | The following are supported: VSU technology Local stacking and remote stacking Inter-chassis link binding in a stack Virtualization via standard service interfaces |
| Zero Configuration | CPE WAN Management Protocol (CWMP(TR069)) |
| Management Features | SNMPv1/v2c/v3, CLI(Telnet/Console), RMON(1, 2, 3, 9), SSH, Syslog, NTP/SNTP, Web, CLI(Telnet/Console), RMON, SSH, Syslog/Debug, NTP/SNTP, FTP, TFTP, Web, and sFLOW |
| Dimensions (W × D × H) | 442 mm × 220 mm × 43.6 mm |
| Rack Height | 1RU |
| MTBF (hours) | >200K |
| Power Supply | AC input: Rated voltage range: 100 V to 240 V Maximum voltage range: 90 V to 264 V Frequency: 50/60 Hz |
| Fan | Fan speed regulating and alarm function |
| Power Consumption | ≤55 W |
| Temperature | Operating temperature: 0oC to 45oC Storage temperature: -40oC to 70oC |
| Relative Humidity | Operating humidity: 10% to 90%RH Storage humidity: 5% to 95%RH |
| Operating Altitude | 0m to 5,000m |
| Lightening Protection on Communication Port | 10kV (Common Mode) |
| Lightning Protection on Power Port | Common Mode 6KV/Differential Mode 6KV |
|
ประกัน |
3 ปี |
