| Frequency response |
20Hz-20kHz, + 0 / -1dB |
| Total harmonic distortion (THD) |
<0.5%, 20Hz-20kHz |
| Intermodulation distortion |
= / <0.35% |
| Conversion Rate |
> 10V / us |
| Voltage gain |
33dB |
| Damping factor |
> 200 (8Ω, 10Hz-400Hz) |
| Signal to noise ratio (20 Hz-20 kHz below rated power, A-weighted sound level) |
> 100dB |
| Crosstalk |
-75dB @ 1kHz, -59dB @ 20kHz, based on rated output power |
| Input sensitivity |
0.775V or 1.4V (rated output power 8Ω) |
| input resistance |
20kΩ balanced, 10kΩ unbalanced |
| Input connector |
One balanced XLR connector or one unbalanced RCA connector per channel |
| Output connector |
One 4-pin Speakon ® and one pair of posts per channel |
| Front panel components |
Power switch, channel gain control knob |
| Rear panel components |
Output mode switch: stereo, parallel, bridge; input sensitivity switch: 0.775V or 1.4V |
| Power Indicator |
Blue LED |
| Signal Indicator |
One green LED per channel |
| Clip Indicator |
One yellow LED per channel |
| Fault Indicator |
One red LED for each channel, indicating that the channel is closed |
| Power cables |
Power plug: 10A, 250V; power cord: CCC 3×1.5mm 2 |
| protection |
Protection circuit against short circuit, no load, switch noise, radio interference |
| Ventilation |
Backward air convection mechanism |
| Cooling |
Internal air exhaust cooling, fan cooling, fast adjustment, temperature protection |
| Dimensions (W × H × D) |
19 ”x 3.46” x 12.45 ”(482 mm x 88 mm x 316.4 mm) |
| Net Weight |
29.7 lb (13.5 kg) |
| Shipping weight |
34.2 lb (15.5 kg) |
