| Drive Bay |
16 x 3.5-inch SAS 12Gb/s, SAS/SATA 6Gb/s
|
| Drive Compatibility |
3.5-inch bays: |
| 3.5-inch SAS/SATA hard disk drives |
| 2.5-inch SAS/SATA hard disk drives |
| 2.5-inch SAS/SATA solid state drives |
| Hot-swappable |
Yes |
| Form Factor |
3U Rackmount |
| Host Interface |
4 x 12Gb/s SAS 3.0 wide ports (4-wide port) Mini-SAS HD (SFF-8644) |
| LED Indicators |
Front panel: HDD 1-16, Power, Status, Link, Fan error |
| Rear panel: SAS connector, Enclosure ID |
| Buttons |
Power |
| Dimensions (HxWxD) |
131.3 × 482.2 × 425.3 mm |
| Weight (Net) |
11.48 kg |
| Weight (Gross) |
16.01 kg |
| Max. number of HDDs/SSDs supported |
16 |
| Hard Drive Type |
3.5″ or 2.5″ SAS 12Gb/s, SAS/SATA 6Gb/s and 3Gb/s drives |
| Operating temperature |
0 – 40 °C (32°F – 104°F) |
| Storage Temperature |
-20 – 70°C (-4°F – 158°F) |
| Relative Humidity |
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit |
550W(x2), 100-240V |
| Power Consumption: Operating Mode, Typical |
207.13 W
|
| Fan |
3 x 80mm, 12VDC |
| System Warning |
Buzzer |
| Management |
Managed via QNAP QTS / QuTS hero OS |
| 1. Supports disk S.M.A.R.T. information |
| 2. RAID expansion enclosure identifier |
| 3. Locate RAID expansion enclosures |
| 4. Locate hard disks on RAID expansion enclosure |
| 5. Smart fan control by detecting system and hard drive temperature |
| 6. In-band SAS firmware update |
| Warranty |
5 Years |
