เครื่องอินเตอร์คอม   ยี่ห้อ Panasonic รุ่น DHI-ASI3214A-W

Function

• Video intercom: video communication, remote unlock, apartment entrance mode and community entrance mode
• Vandal-resistant: If someone move the device, device will send alarm information to guard unit and software management
• Elevator control: call elevator, control elevator (3rd party Option)
• Customized Screen: Prepared 5 types of the picture data, such as “Panasonic”, Developer’s name, Condominium name.
• Time synchronized: device time will synchronize from center (guard unit) automatically
• Leave message: Visitor can leave a voice message with a photo
• External device: Access Controller, access Control Reader, Elevator Controller and Dry Contact
• Web configuration: engineer can set parameters on webpage
• 12V output:12V output can give power supply to external device
• Support 2 locks: First lock connect to outdoor unit directly

Parameters

• Operation system: Linux
• Color camera: 2M Pixels
• Max consumption: ≤3.47W
• Standby consumption: ≤2.28W
• Screen: 5inch
• Operation: Touch button
• Resolution: 480*272
• Voltage: 12~24VDC±10%
• Working Temp: -40°C~70°C
• RAM: 64MB
• Flash: 16MB
• IP grade: IP54
• Port: RJ45
• Protocol: TCP/IP
• Audio and video codec：G.711/H.264
