• Integral rigging hardware for simple connection of VRX932LA line-arrays and optional array frame.
• 18 inch, 2268H Differential Drive® woofer for extended low-frequency output
• Large port area for reduced distortion
• 20 mm threaded pole socket for solid, secure satellite speaker mounting

Specifications

• Power Rating:    800 W / 1600 W / 3200 W
• Frequency Range:   31 Hz – 220 Hz
• Dimensions (H x W x D) : 508 mm x 597 mm x 749 mm (20.0 in x 23.5 in x 29.5 in)
• Frequency Range (-10dB):   31 Hz – 220 Hz
• Recommended Crossover Frequencies:  80 Hz, 24 dB / octave HPF80 Hz, 24 dB / octave LPF
• System Maximum SPL:   130 dB SPL peak
• System Sensitivity (1w @ 1m):    95 dB SPL
• LF Driver:    1 x JBL 2268H 457 mm (18 in) Differential Drive woofer
• Nominal Impedance:      8 ohms
• Active Tunings: Tunings available at www.jblpro.com
• Enclosure:    Rectangular, 18 mm, 13-ply birch plywood
• Suspension / Mounting : Optional VRX932LA-AF line array frame kit or 10mm eyebolt
• Finish:   Black DuraFlex™ finish
• Grille:    Powder coated, black, 16-gauge perforated steel with acoustical transparent charcoal foam backing.
• Inputs:  Neutrik® Speakon® NL-4 (x2)
• Net Weight (each):          37 kg (81 lb)
• Optional Accessories:     SRX718S-CVR: Pull-over padded coverSS4-BK: Adjustable, heavy-duty pole, M20 thread to 35 mmWK-4: Caster kitVRX-AF: Array Frame KitM-10 eyebolt kit
• Outputs:      1 x XLR
