7Y99A00YSG
- Supports the AMD EPYC 7002 and EPYC 7003 families family of processors
- Supports processors with up to 64 cores and 128 threads, core speeds of up to 4.1 GHz, and TDP ratings of up to 280W.
- Support for up to 16 TruDDR4 memory DIMMs, with 8 memory channels and 2 DIMMs per channel. With 1 DIMM installed per channel (8 DIMMs total), memory operates at up to 3200 MHz. With 2 DIMMs per channel (16 DIMMs total), memory operating at up to 2933 MHz.
- Using 128GB DIMMs, the server supports up to 2TB of system memory.
- Supports up to three single-width GPUs, each up to 75W. A 3:1 ratio of GPUs to CPUs means substantial processing power is available with just one CPU.
- Supports up to 16x 2.5-inch hot-swap drive bays, by using combinations of front-accessible (up to 10 bays), mid-accessible (4 bays), and rear-accessible (2 bays).
- Supports four 3.5-inch drive bays for lower-cost high-capacity storage. 2.5-inch and 3.5-inch drive bays can be mixed in several combinations.
7Y99S64300
- AMD EPYC 7272 12Core 24Thread 120W 2.9GHz 64MB Cache
- 16GB TruDDR4 2933 MHz RDIMM
- 2x 960GB SSD SATA Entry Hard Disk 6GB
- ThinkSystem RAID 530-8i PCIe 12Gb Adapter
- (Support RAID-0/1/10/5/50)
7Y99S64400
- CPU : AMD EPYC 7272 12C 120W 2.9GHz Processor
-
RAM : 16GB TruDDR4 2933MHz (1Rx4 1.2V) RDIMM-A
-
HDD : 2x ThinkSystem 2.5″ 1.2TB 10K SAS 12Gb Hot Swap 512n HDD
-
RAID : RAID 530-8i PCIe 12Gb Adapter
7Z71A014AP
-
CPU :Intel® Xeon® Silver 4309Y Processor (8C, 105W, 12M Cache, 2.80 GHz)
-
RAM :1x16GB TruDDR4 3200MHz (2Rx8 1.2V) RDIMM
-
HDD :No HDD, Drive bays 4x 3.5″ SAS
-
RAID :RAID 930-8i 2GB Flash PCIe 12Gb Adapter
7Z71A015AP
- Product type: PC server
- Product series: ThinkSystem SR630 V2
- Shape/Height: 1U rack server
- Processor: Up to 2x 3rd Generation Intel Xeon Scalable Processors, up to 40 cores, up to 270W TDP
- Number of drive bays: Up to 4 x 3.5″ + 2 x 2.5″ bays, or 12 x 2.5″ bays, or 16 EDSFF bays, 2 x M.2 boot drive bays (RAID1), 2 7mm boot drive bays (rear, RAID1)
- Memory: Up to 8TB (32 DDR4 memory slots, using 256GB 3DS RDIMMs), supports up to 16 Intel Optane Persistent Memory 200 Series Modules (PMem)
7Z71A016AP
- Product type: PC server
- Product series: ThinkSystem SR630 V2
- Shape/Height: 1U rack server
- Processor: Up to 2x 3rd Generation Intel Xeon Scalable Processors, up to 40 cores, up to 270W TDP
7Z71A019AP
-
CPU :Intel® Xeon® Silver 4309Y Processor (8C, 105W, 12M Cache, 2.80 GHz)
-
RAM :1x16GB TruDDR4 3200MHz (2Rx8 1.2V) RDIMM
-
HDD :No HDD, Drive bays 8x 3.5″ SAS
-
RAID :RAID 930-8i 2GB Flash PCIe 12Gb Adapter
-
OPTICAL :No Optical Drive (Optional)
7Z71A01BAP
- processor : 20 cores: 40 threads: Xeon Silver 4316 2.3GHz: 30MB
- Number of CPUs installed : 1 unit (maximum 2 units)
- memory : 16GB(1x16GB 2Rx8)PC4-25600 Reg DDR4-3200 / Max 1.5TB
7Z71A01HAP
- Product type: PC server
- Product series: ThinkSystem SR630 V2
- Shape/Height: 1U rack server
- Processor: Up to 2x 3rd Generation Intel Xeon Scalable Processors, up to 40 cores, up to 270W TDP
- Number of drive bays: Up to 4 x 3.5″ + 2 x 2.5″ bays, or 12 x 2.5″ bays, or 16 EDSFF bays, 2 x M.2 boot drive bays (RAID1), 2 7mm boot drive bays (rear, RAID1)
- Memory: Up to 8TB (using 32 DDR4 memory slots, 256GB 3DS RDIMM), supports up to 16 Intel Optane Persistent Memory 200 Series modules (PMem)
- Expansion slots: up to 3 PCIe 4.0 slots, 1 OCP 3.0 slot, 1 standard HBA/RAID adapter slot with cable that does not occupy a PCIe slot
- GPUs: Up to 3 single-width 75W GPUs
7Z71A01JAP
- Product type: PC server
- Product series: ThinkSystem SR630 V2
- Shape/height: 1U rack server
- Processor: Up to 2x 3rd Generation Intel Xeon Scalable Processors, up to 40 cores, up to 270W TDP
- Number of drive bays: Up to 4 x 3.5″ + 2 x 2.5″ bays, or 12 x 2.5″ bays, or 16 EDSFF bays, 2 x M.2 boot drive bays (RAID1), 2 7mm boot drive bays (rear, RAID1)
- Memory: Up to 8TB (using 32 DDR4 memory slots, 256GB 3DS RDIMM), supports up to 16 Intel Optane Persistent Memory 200 Series modules (PMem)
7Z71A01LAP
- Processor Option
- ThinkSystem 16GB TruDDR4 3200MHz (2Rx8 1.2V) RDIMM
- Lenovo ThinkSystem RAID 930 Series Internal RAID Adapters
- Drive bays 8x 2.5″ SAS
- OCP I350 1Gb
- Slots 2x LP Gen3
- 750Watts Fixed Power Supply Internal
- Front VGA Yes
- XClarity Controller Standard
- Fans 6x Std
- Rail kit Slide
- 3 years warranty 24x7x4, Part and Labor, On-site*
7Z71A01PAP
-
CPU :Intel® Xeon® Silver 4309Y Processor (8C, 105W, 12M Cache, 2.80 GHz)
-
RAM :1x16GB TruDDR4 3200MHz (2Rx8 1.2V) RDIMM
-
HDD :No HDD, Drive bays 4x 3.5″ SAS
-
RAID :RAID 930-8i 2GB Flash PCIe 12Gb Adapter
