| Projection System |
DLP |
| Native Resolution |
XGA (1024 x 768) |
| Brightness* |
3200 lumens |
| Contrast Ratio |
13000:1 |
| Display Color |
1.07 Billion Colors |
| Lens |
F=2.56-2.68, f=22.04-24.14mm |
| Aspect Ratio |
Native 4:3 (5 aspect ratio selectable) |
| Throw Ratio |
1.96-2.15 (78″ @ 3.1m) |
| Image Size (Diagonal) |
60″-180″/ 300′ (Clear Focus/ Maximum) |
| Zoom Ratio |
1.1:1 (Powered) |
| Keystone Adjustment |
1D, Vertical +/- 40 degrees |
| Projection Offset |
120% ±5% |
| Resolution Support |
VGA (640 x 480) to UXGA (1600 x 1200) |
| Horizontal Frequency |
15K-102KHz |
| Vertical Scan Rate |
23-120Hz |
| Dimensions(W x H x D) |
- 283 x 95 x 222mm (include feet)
- 283 x 88.7 x 222mm (exclude feet)
|
| HDTV Compatibility |
480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| Video Compatibility |
NTSC, PAL, SECAM |
| Weight |
1.8kg |
| Audible Noise Type |
33/ 28 dBA (Normal/ Economic mode) |
| Power Supply |
AC100 to 240V, 50 to 60Hz |
| Power Consumption |
Normal 270W, Eco 220W, Standby < 0.5W |
| On-Screen Display Languages |
Arabic/ Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/ French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/ Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/ Russian/ Simplified Chinese/ Spanish/ Swedish/ Turkish/ Thai/ Traditional Chinese (28 Languages) |
| Picture Modes |
Dynamic/ Presentation/ sRGB/ Cinema/ User 1/ User 2 |
| 3D Support and Compatibility |
- Frame Sequential: Up to 720p 60Hx (Video), Up to WXGA 120Hz (PC Timing)
- Side by Side: Up to 1680 x 1050 60Hz (PC Timing)
- Top Bottom: Up to 1680 x 1050 60Hz (PC Timing)
|
| Interface |
- Computer In (D-sub 15pin) x 2 (Share with component)
- Monitor Out (D-sub 15pin) x 1
- Composite Video In (RCA) x 1
- S-Video In (Mini DIN 4pin) x 1
- Audio In (Mini Jack) x 1
- Audio Out (Mini Jack) x 1
- Speaker 2W x 1
- USB (Type mini B) x 1 (Download & Page/down)
- RS232 (DB-9pin) x 1
- IR Receiver x 1 (Front)
|
| Accessories (Standard) |
- Remote Control w/ Battery
- Power Cord (by region)
- Quick Start Guide
- Warranty Card (by region)
- VGA (D-sub 15pin) Cable
|
| Accessories (Optional) |
- Spare Lamp Kit
- Ceilling Mount
- 3D Glasses
- Carry Bag
|
