| Model |
SH963 |
| Projection System |
DLP |
| Native Resolution |
1080p (1920 x 1080) |
| Brightness* (ANSI Lumens) |
6000AL |
| Contrast Ratio |
8300:01:00 |
| Display Color |
1.07 Billion Colors |
| Lens |
F=2.48~2.81, f=24.1~36.15mm |
| Aspect Ratio |
Native 16:9 (5 aspect ratio selectable) |
| Throw Ratio |
1.62~2.43(55.7″@ 2m) |
| Image Size (Diagonal) |
28″~300″ |
| Zoom Ratio |
1.5:1 |
| Lamp Type |
350W x 2 |
| Lamp Mode (Normal/Economic/SmartEco/LampSave/LumenCare)* |
2000/2500/NA hours |
| Keystone Adjustment |
2D, Vertical & Horizontal ± 30 degrees |
| Projection Offset |
Vertical: ±120%(±5%); Horizontal: ±40%(±5%) |
| Resolution Support |
VGA(640 x 480) to WUXGA_RB(1920X1200) *RB=Reduced blanking |
| Horizontal Frequency |
31K~92KHz |
| Vertical Scan Rate |
23~85Hz |
| Interface |
- Computer in (D-sub 15pin) x 1(Share with component)
- Monitor out (D-sub 15pin) x 1
- HDMI x 2
- Component Video in (5BNC) x 1
- Composite Video in (RCA) x 1
- Audio in (Mini Jack) x 1
- Audio out (Mini Jack) x 1
- Speaker 10W x 1
- LAN (RJ45) x 1 (LAN Control)
- USB (Type Mini B) x 1 (Download)
- 12V Trigger x 1
- RS232 (DB-9pin) x 1
- IR Receiver x 2 (Front+Rear)
|
| Dimensions (W x H x D mm) |
443 x 167 x 355 mm |
| HDTV Compatibility |
480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| Video Compatibility |
NTSC, PAL, SECAM |
| Audible Noise (Normal/Economic Mode) |
44/40/41/38 db (Dual Brightness / Dual Reliable / Single Alternative / Single Eco) |
| On-Screen Display Languages |
- ENGLISH/ 繁體中文/ FRANÇAIS/ ESPAÑOL/ DEUTSCH/ ITALIANO/ 简体中文/ 한국어/ 日本語 / РУССКИЙ/ Nederlands/ Português/ svenska/ čeština/ polski/ โปรตุเกส/ Türkçe (17 Languages)
|
| Picture Modes |
Dynamic/Presentation/sRGB/Cinema/User 1/User 2 |
| Accessories (Standard) |
- Remote Control w/ Battery
- Power Cord (by region)
- User Manual CD
- Quick Start Guide
- Warranty Card (by region)
- VGA(D-sub 15pin) Cable
|
| Accessories (Optional) |
- Presentation Plus P/N: 65.J9306.002
- Spare Lamp Kit
- Ceilling Mount
- 3D Glasses
|
| Power Supply |
AC100 to 240 V, 50 to 60 Hz |
| Power Consumption |
940W (typical), Standby<0.5W |
| Weight |
13KG |
