ชุดไมค์ประชุมระบบดิจิตอล ยี่ห้อ SHURE รุ่น CM 6680 F

Features

• Standard conference unit for chairmen
• Fully digital audio transmission
• Daisy chain topology with loop-through connections or startopology using junction boxes
•  CAT 5e (or higher) F/UTP or U/FTP (screened) cabling
•  Maximum of 3800 conference units per system
• Support for four microphone operation modes; Automatic,FIFO, Manual and VOX (voice activation)
•  Support for three microphone interrupt modes enabling ‘pingpong’ mode
• Auto off of microphones
• Lockable XLR gooseneck microphone connector
• One high-quality loudspeaker
• A channel selector supporting the floor channel and 31interpretation channels
•  One headphone socket
• One chip card reader
• A microphone button with LED indicator for speak
•  A delegate off button with LED indicator for delegates off
• Five voting buttons for:
  •  3-button voting
  • 5-button voting
  •  Attendance check
• By connecting a PC running the SW6000 Conference
  Management Software, the following additional feature can be
  made available:
•  Login with chip card

Electrical

• Frequency response (channel selector) 65 Hz-16 kHz
• Frequency range(loudspeaker) 150 Hz-15 kHz
• Power consumption 3.5 W
• Power maximum(loudspeaker) 3.0 W RMS
• Microphone connection 3-pin female XLR
• Headphone connection 3.5 mm jack female stereosocket
