| Projection Technology |
RGB liquid crystal shutter projection system (3LCD) |
| Specifications of Main Parts |
| LCD: |
| Size |
0.61” wide panel with MLA (D9.8, C2Fine, 12Bit) |
| Native Resolution |
1080p (1920 x 1080) |
| Projection Lens: |
| Type |
Optical Zoom (Manual) / Focus (Manual) |
| F-Number |
1.58 – 1.72 |
| Focal Length |
16.9 – 20.28 mm |
| Zoom Ratio |
1 – 1.2 |
| Throw Ratio |
1.22 – 1.47 (Wide – Tele) |
| Lamp |
| Type |
200W UHE |
| Life (Normal/Eco)*¹ |
4,000 hours / 7,500 hours |
| Screen Size (Projected Distance) |
| Zoom Wide |
34” – 332” [0.91 – 9.11 m] |
| Zoom Tele |
34” – 332” [1.09 – 10.94 m] |
| Standard Size |
60″ screen 1.62 – 1.95 m |
| Brightness |
| White Light Output (Normal/Eco) |
2,200lm |
| Colour Light Output |
2,200lm |
| Contrast Ratio |
35,000:1 |
| Video Quality |
Interlace-Progressive Conversion, 3D Y/C Separation, Noise Reduction |
| Supported Video Signal |
480i / 576i / 480p / 576p / 720p / 1080i / 1080p |
| Colour Mode |
Dynamic, Bright Cinema, Natural, 3D Dynamic, 3D Cinema |
| Internal Speaker(s) |
| Sound Output |
5W (Monaural) |
| Keystone Correction |
| Vertical / Horizontal |
± 30° / ± 30° (Slide Bar) |
| Auto Keystone Correction |
Yes (Vertical) |
| Connectivity |
| Analog Input |
| D-Sub 15 pin |
1 (Blue) |
| Video Input |
| Composite |
RCA x 1 (Yellow) |
| Digital Input |
| HDMI |
2 (one of terminal supports MHL) |
| Audio Input |
| RCA (White / Red) |
RCA (White) x 1 (Left ch), RCA (Red) x 1 (Right ch) (in common with Analog RGB Audio terminal) |
| Audio Output |
| Stereo Mini Jack |
1 |
| USB Type A |
1 (for Slideshow, Firmware update) |
| USB Type B |
1 mini-USB (for service) |
| Wireless Specification |
| Supported Speed For Each Mode |
- IEEE 802.11n (2.4GHz): 130 Mbps*3
- IEEE 802.11n (5GHz): 130 Mbps*3
|
| Supported Connection Mode |
Wi-Fi Direct |
| Adjustment Functions |
| Six Axis Colour Adjustment |
Hue / Saturation / Brightness for Each of RGBCMY are adjustable |
| Frame Interpolation |
Off / Low / Normal / High (2D and 3D Mode) |
| Detail Enhancement |
0 to 100 |
| Split Screen |
Yes |
| Aspect Mode |
- Auto / Normal / Full / Zoom
- (Auto appears only when HDMI is selected.)
|
| 3D Features |
| 3D Display |
Auto / 3D / 2D |
| 2D – 3D Conversion |
Off / Weak / Medium / Strong |
| 3D Format |
Side by Side / Top and Bottom |
| 3D Depth |
±10 |
| Operating Temperature |
- 5 – 35 °C <41 – 95 °F> ( 0m / 0ft – 2,286m / 7,500ft )
- 5 – 30 °C <41 – 86 °F> ( over 2,286m / 7,500ft )
|
| Operating Altitude |
0 – 3,000 m <0 – 9,843 ft> |
| Direct Power On/Off |
Yes / N/A |
| Start Up Period |
Under 15 seconds, Warm-up period: 30 seconds |
| Cool Down Period |
Under 5 seconds |
| Power Supply Voltage |
100 – 240 V AC ±10%, 50/60 Hz |
| Power Consumption (220-240V) |
| Lamp On (Normal/Eco) |
291W / 224W |
| Standyby |
0.28W |
| Dimension Excluding Feet (D X W X H) |
245 x 297 x 114 mm |
| Weight |
3.1kg |
| Fan Noise (Normal / Eco) |
37dB / 29dB |
