HP-97D50PE

1/2.7″ Smartsens CMOS progressive scan
2592(H)x1944(V), 5.0MP
H.265, H.264, Triple stream
Fixed lens 2.8mm/M12
IR Array LED x1 Array, Distance 20-30M.

SAFEANDSOUND ตัวแทนจำหน่าย ผลิตภัณฑ์ กล้องวงจรปิด เครื่องเสียง ชุดประชุม และบริการติดตั้ง สนใจผลิตภัณฑ์ กล้องวงจรปิด ภาพคมชัด สีสวย หรือ เครื่องเสียง ชุดประชุม คุณภาพดี และบริการติดตั้งอีกทั้งบริการหลังขาย ปรึกษาฟรี!! หรือ นัดสำรวจหน้างานฟรี พร้อมทำใบเสนอราคา โทรเลย 089-8415456 หรือ 095-4466266 24ชั่วโมง

0 People watching this product now!

กล้องวงจรปิด IP DOME ยี่ห้อ HI- VIEW รุ่น HP-97D50PE

1/2.7″ Smartsens CMOS progressive scan
2592(H)x1944(V), 5.0MP
H.265, H.264, Triple stream
Fixed lens 2.8mm/M12
IR Array LED x1 Array, Distance 20-30M.
IR CUT (IR Filters)
WDR, DEFOG, BLC, HLC, 3D-DNR
Email alarm, Motion alarm, FTP alarm
Protection Level IP67
Mic-Built-in x1, RJ45 x1 (100 Mbps)
Power supply 12VDC / POE (IEEE802.3af)

Model	HP-97D50PE
Image Sensor	1/2.7″ Smartsens SC5238 CMOS progressive scan
CPU	NT98513
Pixels	5MP
Min.lllumination	0.0236 lux@F2.0< AGC ON, 0 lux with IR 0.0085 lux@F1.2, AGC ON, 0 lux with IR
Lens
Mount Type	M12
Focal Length	2.8mm.
Iris Type	Fixed iris
Horizontal Field of View	93.4ํ
Infrared
Day / Night Mode	Auto/day/night/timing
IR-CUT Filter	Supported
IR Array LED	x1 Array
IR Array Distance	20-30M.
Infrared Mode	Auto/on/off
Smart IR	Supported (On/Off)
Display
Image Parmeter	3 type (common,day, night) and schedule setting
Brihtness Adjust	Supported
Contrast Adjust	Supported
Hue Adjust	Supported
Saturation Adjust	Supported
Sharpness Adjust	Supported
Noise Reduction	Supported 3D DNR
Defog	supported
WDR	Supported
BLC	Supported
HLC	Supported
Anti-Filcker	Supported 50Hz/60Hz
White Balance	Supported (Auto/indoor/outdoor/manual)
Frequency	Supported 50Hz/60Hz
Exposure Mode	Supported auto/manual (1/25s-1/100,000s)
Gain	Supported
Image Mirror	Supported
Image Flip	Supported
Backlight Compensation	Supported
E-zoom	Supported
Images
Video Compression	H.265,H.264
Audio Compression	G711A, G711U
Compression Standard	Base line, Main Profile, High Profile
Stream	Triple stream
Image Resolution	Main stream 2592×1944, 2560×1440, 1920×1080, 1280×720 Sub stream 1280×720, 704×576, 352×288 Third stream 704×576, 480×240, 352×288
Image Frame Rate	Main stream 259×1944@20fps(PAL),2560×1440@25fps(PAL), 1920×1080@25fps(PAL),1280×720@25fps(PAL) Sub steam 1280×720@12fps(PAL), 704×576@25fps(PAL), 352×288@25fps(PAL) Third steam 704×576@25fps(PAL), 480×240@25fps(PAL), 352×288@25fps(PAL)
Bit Rate	128 Kbps – 5 Mbps
Video Encode Slice Split	Supported
Water Mark	Supported
OSD	Supported
Date and Time	Supported DST, NTP, synchroniza with PC,manual
Video Mask	Supported (Max. 4 areas)
ROI	supported (Max. 3 areas)
Alarm
Motion	Supported
Motion Sensitivity	Supported
Motion Schedule Setting	Supported
Motion Alarm Triggering	Email/FTP
Alarm Server	Supported
Network
Network Protocols	IPv4, IPv6, PPPoE, HTTP, HTTPS, DNS, 802.1X, RTSP, UPNP, SMTP, FTP, QoS, ONVIF, DST, NTP
Test IP Address Function	Supported
DDNS Protocol	autoddns.com/88ip.net/dns2p.net/meibu.com/dyndns.com/no-ip.com/dvrdydns/mintdns/123ddns.com
Free DDNS	www.autoddns.com, dvrdydns, Etc.
Application Programming	ONVIF profile S
Online Connection	Support simultaneous monitoring for up to 6 users
User Interface	IE 11,NVMS2.0, APP (Superliveplus)
Security
User Account Managent	Supported
IP/MAC Address Filter	Support (black and white list)
Locking Once lllegal Login	Supported
Online User Checking	Supported Kick-off
Maintenance
Backup and Restore	Supported export/import setting, load default
Reboot	Supported time/date schedule
Syatem Upgrade	Supported
Log Serach	Supported export log
Interfaces
RJ45	x1 (Speed 100Mbps), POE
Mic Built-in	x1
Power lnput	x1 (DC jack)
Environmental
Operating Temperature	-30ํC -+60ํC (-22ํF-140ํF)
Operating Humidity	95% or less (non-condensing)
Water-Proof	IP67
Electrical
Power Supply	12V DC +- 10% / PoE (IEEE802.3af)
Power Consumption	IR Off:26mA/2.6W, IR On:38mA/5W
Mechanical
Weight	Approx.0.45KG
Dimensions	94.6×82.8
