SWITCH ยี่ห้อ ARUBA รุ่น JZ336A

• Antenna Internal
• Antenna Qty 4
• Directivity Omni-directional
• Gain Level 5.4 dBi
• Dimensions & Weight (Shipping)
• Shipping Depth 11.8 in
• Shipping Height 4.1 in
• Shipping Weight 4.25 lbs
• Shipping Width 11.2 in
• Environmental Parameters
• Humidity Range Operating 5 – 93% (non-condensing)
• Max Operating Temperature 122 °F
• Min Operating Temperature 32 °F
• Expansion / Connectivity
• Interfaces 1 x HPE Smart Rate – RJ-45 ¦ 1 x 5GBase-T – RJ-45 ¦ 1 x USB 2.0 – Type A ¦ 1 x console – micro-USB
• Internet of Things (IoT)
• Communications Technology Bluetooth, Zigbee
• Internet of Things (IoT) Compatible Yes
• Manufacturer Warranty
• Service & Support Limited warranty – lifetime
• Miscellaneous
• Compliant Standards EN 60950, IEC 60950, UL 60950, UL 2043, FCC, EN 60601-1-2, EN 60601-1-1, EMC 2014/30/EU, LVD 2014/35/EU, ISED, RED 2014/53/EU
• Included Accessories Base bracket
• MTBF 114 years
• Networking
• Capacity Wireless clients per Wi-Fi radio: 1024 ¦ OFDMA units: 37 ¦ BSSIDs per radio: 16
• Compliant Standards IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac, IEEE 802.3bz, IEEE 802.3bt, IEEE 802.11ax
• Connectivity Technology Wireless
• Data Link Protocol IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, ZigBee, IEEE 802.11ac, Bluetooth 5.0, IEEE 802.11ax
• Data Transfer Rate 2.4 Gbps
• Encryption Algorithm WPA, WPA2, WPA3
• Features Trusted Platform Module (TPM), LACP support, Adaptive Radio Management (ARM), Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-
• forming (TxBF) ready, Direct Sequence Spread Spectrum (DSSS), Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), Advanced Cellular Coexistence (ACC), ClientMatch, cyclic
• shift diversity (CSD), AppRF technology, MU-MIMO technology, packet aggregation A-MPDU, packet aggregation A-MSDU, Air Monitor (AM), Intelligent Power Monitoring (IPM), Dynamic
• Frequency Selection (DFS), Secure Core Technology (SCT), High-Throughput (HT) support, 4×4 MU-MIMO technology, LED off mode, Energy-Efficient Ethernet (EEE), Orthogonal
• Frequency Division Multiplexing (OFDM), Aruba AirMatch, spectrum analyzer, Very High Throughput (VHT) support, security slot (Kensington security lock compatible), Orthogonal
• Frequency Division Multiple Access (OFDMA), unified AP support, custom deep-sleep mode, High Efficiency (HE) support, Target Wait Time (TWT)
• Form Factor External
• Frequency Band 2.4 GHz, 5 GHz
• Line Coding Format CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, OFDM, 1024 QAM, OFDMA
• Performance Maximum data rate (2.4 GHz): 1.150 Mbps ¦ Maximum data rate (5 GHz): 2.4 Gbps ¦ Aggregate bandwidth: 3.55 Gbps
• Spread Spectrum Method OFDM, DSSS
• Status Indicators System, status
• Power
• Power Consumption Operational 26.4 Watt
• Power Over Ethernet (PoE) Supported PoE
• Software / System Requirements
• OS Required ArubaOS, InstantOS
