| Frequency response |
50 Hz to 20 kHz (+1 / -3 dB) |
| Distortion |
<0.5% |
| Bass control |
±10 dB @ 100 Hz |
| Treble control |
±10 dB @ 10 kHz |
| Channel separation |
>70 dB @ 1 kHz |
| Priority mute |
>40 dB |
| Dynamic range |
100 dB |
| Mic/line input |
1 x |
| Connectors |
5‑pin DIN, 3‑pin XLR, balanced, with phantom power |
| Sensitivity |
1 mV (mic), 200 mV (line) |
| Impedance |
>1 kohm (mic); >5 kohm (line) |
| S/N (flat at max volume) |
>63 dB (mic); >70 dB (line) |
| S/N (flat at min volme/muted) |
>75 dB |
| CMRR |
>40 dB (50 Hz – 20 kHz) |
| Headroom |
>25 dB |
| Speech filter |
-3 dB @ 315 Hz, high-pass, 6 dB/oct |
| Phantom power supply |
16 V via 1.2 kohm, (mic mode only) |
| Line input |
3 x |
| Connector |
Cinch, stereo converted to mono, unbalanced |
| Sensitivity |
200 mV |
| Impedance |
22 kohm |
| S/N (flat at max volume) |
>70 dB |
| S/N (flat at min volume/muted) |
>75 dB |
| Headroom |
>25 dB |
| Master output |
1 x |
| Connector |
3-pin XLR, balanced |
| Nominal level |
1 V |
| Impedance |
<100 ohm |
| Tape output |
1 x |
| Connector |
Cinch, 2 x mono |
| Nominal level |
350 mV |
| Impedance |
<1 kohm |
| Headphone output |
1 x |
| Connector |
6.3 mm jack stereo, signal mono |
| Nominal level |
3 V |
| Impedance |
<100 ohm |
| S/N (flat at max volume) |
>70 dB |
| S/N (flat at min volume/muted) |
>75 dB |
| Headroom |
>25 dB |
| Master output |
1 x |
| Connector |
3-pin XLR, balanced |
| Nominal level |
1 V |
| Impedance |
<100 ohm |
| Tape output |
1 x |
| Connector |
Cinch, 2 x mono |
| Nominal level |
350 mV |
| Impedance |
<1 kohm |
| Headphone output |
1 x |
| Connector |
6.3 mm jack stereo, signal mono |
| Nominal level |
3 V |
| Impedance |
<100 ohm |
| Zone relays |
5 A |
| Contacts voltage |
250 V |
| Contacts current |
8 A |
| Interconnection input / emergency |
1 x |
| Connector |
3-pin XLR, balanced |
| Sensitivity |
200 mV (interconnection),100 mV to 1 V adjustable (emergency) |
| Impedance |
>10 kohm |
| VOX threshold |
45 mV (emergency) |
| Interconnection output |
1 x |
| Connector |
3-pin XLR, balanced |
| Nominal level |
200 mV |
| Impedance |
<100 ohm |
| Relay contacts |
30 V, 1 A |
| DC supply output voltage |
24 V, 250 mA max |
| Dimensions (H x W x D) |
100 x 430 x 270 mm(19″ wide, 2U high) |
| Weight |
Approx. 5 kg |
| Mounting |
Standalone, 19″ rack |
| Color |
Charcoal |
| Operating temperature |
-10 ºC to +55 ºC (14 ºF to +131 ºF) |
| Storage and transport temperature |
-40 ºC to +70 ºC (-40 ºF to +158 ºF) |
| Relative humidity |
<95% |
