Panel Size

1-Chip DLP 15mm (0.65″)

Light Source

LED

Resolution

WXGA (1280 x 800) 16:10 aspect ratio

Light Output (Brightness) ANSI Lumens

3500 (Normal)

Contrast Ratio

30,000:1

Lens

Built-in

System Life (Hours)

20,000

Lens Zoom

Manual Zoom x 1.7

Lens Focus

Manual Focus

Lens Shift

Manual

Throw Distance

0.9m – 9.2m (WIDE) / 1.5m – 15.8m (TELE)

Distance to Width Ratio/ Throw Ratio (:1)

1.4 (WIDE), 2.4 (TELE)

Diagonal Display Size

30 – 300″

Digital Keystone Correction

Horizontal ± 30°, Vertical ± 30°

Digital Input

HDMI/MHL x 1 (Supporting HDCP decoding), HDMI x 1 (Supporting HDCP decoding), HDBaseT (RJ-45) x 1

Analogue Input

15-pin Mini D-Sub x 1, RCA Jack x 1

Video Output

15 pin Mini D-Sub x 1, HDMI x 1 (Supporting HDCP decoding)

Audio Input

3.5mm Stereo Mini Jack x 1, RCA Jack (L,R) x 1, HDMI x 2, HDBaseT x 1

Audio Output

3.5mm Stereo Mini Jack x 1

RS-232C Control

1 x 9-pin D-Sub

Wireless LAN

Yes (Optional)

Wired LAN

Yes

USB Type A

Used for wireless network

USB Type B

Used for remote control mouse

Power Supply

AC 100 – 120V (560W), AC 220 – 240V (550W)

Operating Power Consumption

550 W

Standby Power Consumption

Less than 0.5W

Weight

14.6kg

Dimensions (W x H x D) (Without feet)

471 x 148 x 455mm

Noise

27dB (Mid), 34dB (High mode), 21dB (Low mode)

Supplied Accessories

Power Cable (1.8m), Computer Cable (2.0m), Remote Control, 2 x AA Batteries, Lens Cover, Lens Cap, Adaptor Cover (for USB Wireless Adaptor), Security Label, User Manual (CD), User Manual (Book), Application CD, Adapter cover, Terminal cover A, Terminal cover B, HDMI cable holder (x1), Cable tie – large (x1), Cable tie – medium (x1), Cable tie – small (x3), HDMI Cap (x2), HDBaseT Cap (x1)

Optional Accessories

Wired Remote Control (HL03131), USB Wireless Adaptor (USB-WL-11N)

Remote Control

HL03037

Warranty

20,000 hours / 5 years (whichever comes first)
