SWITCH ยี่ห้อ ARUBA รุ่น R4W43A

Specification

• Hardware Variants
• Built-in Omni Directional Antennas
• 5 GHz Antennas 5.4 dBi
• 2.4 GHz Antennas 3.2 dBi
• BLE/802.15.4 Antennas 3.3d Bi
• Wi-Fi Radio Specifications
• AP type
• Outdoor Hardened, Wi-Fi 6 dual radio, 5 GHz 2×2 MIMO and 2.4 GHz 2×2 MIMO
• Software-configurable dual radio supports 5 GHz (Radio 0) and 2.4 GHz (Radio 1)
• 5GHz
• Two spatial stream Single User (SU) MIMO for up to 1.2 Gbps wireless data rate with individual 2SS HE80 802.11ax client devices, or with two 1SS HE80 802.11ax MU-MIMO capable client devices simultaneously
• 2.4GHz
• Two spatial stream Single User (SU) MIMO for up to 574 Mbps (287 Mbps) wireless data rate with individual 2SS HE40 (HE20) 802.11ax client devices or with two 1SS HE40 (HE20) 802.11ax MU-MIMO capable client devices simultaneously
• Available channels
• Dependent on configured regulatory domain
• Supported radio technologies
• 802.11b: Direct-sequence spread-spectrum (DSSS)
• 802.11a/g/n/ac: Orthogonal frequency-division multiplexing (OFDM)
• 802.11ax: Orthogonal frequency-division multiple access (OFDMA) with up to 16 resource units (RU)
• Supported modulation types
• 802.11b: BPSK, QPSK, CCK
• 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM (proprietary extension)
• 802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM (proprietary extension)
• 802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM
• 802.11n high-throughput (HT) support
• HT 20/40
• 802.11ac very high throughput (VHT) support
• VHT 20/40/80
• 802.11ax high efficiency (HE) support
• HE20/40/80
• Transmit power
• Configurable in increments of 0.5 dBm
• Maximum (conducted) transmit power (limited by local regulatory requirements)
• 2.4 GHz band: +23 dBm per chain, +26 dBm aggregate (2×2)
• 5 GHz band: +23 dBm per chain, +26 dBm aggregate (2×2)
• Note: conducted transmit power levels exclude antenna gain.
• Maximum EIRP (limited by local regulatory requirements):
