24-Port PoE Switch ยี่ห้อ Ruijie รุ่น RG-S2928G-E V3

Product Specification
Overview	Ruijie RG-S2928G-E V3 L3-Managed Gigabit Switch 24 Port, 4 Port SFP (Non Combo) รองรับ Static Routing, OSPF, VRRP, VLAN, DHCP Snooping, VSU, QOS ICT Spec อุปกรณ์กระจายสัญญาณ (L2 Switch) ขนาด 24 ช่อง แบบที 2
Model	RG-S2928G-E V3
Ports	24 10/100/1000BASE-T ports 4 1G SFP ports (non-combo)
Fan Slots	Fanless
Management Ports	1 console port
Switching Capacity	Up to 256Gbps
Packet Forwarding Rate	Up to 96Mpps
Port Buffer	1.5MB
ARP Table	1,000
MAC Address	Up to 16K
Routing Entries	500
IP Host Entries (IPv4/IPv6)	500 (IPv4/IPv6)
ACL Entries	Up to 1,500
ACL	Standard/Extended/Expert ACL, Extended MAC ACL, ACL 80, IPv6 ACL, ACL logging, ACL counter, ACL remark, Global ACL, ACL redirect
QoS	802.1p/DSCP/TOS traffic classification; Multiple queue scheduling mechanisms, such as SP, WRR, DRR, SP+WFQ, SP+WRR, SP+DRR; Input port-based speed limit; Port-based traffic recognition; Each port supports 8 queue priorities
VLAN	4K 802.1q VLANs, Port-based VLAN, MAC-based VLAN, Protocol-based VLAN, Private VLAN, Voice VLAN, QinQ, IP subnet-based VLAN, GVRP
QinQ	Basic QinQ, Flexible QinQ, 1:1 VLAN switching
Link Aggregation	AP, LACP, Flow balance
Port Mirroring	Many-to-one mirroring, One-to-Many mirroring, Flow-based mirroring, Over devices mirroring, VLAN-based mirroring, VLAN-filtering mirroring, AP-port mirroring, RSPAN, ERSPAN
Spanning Tree Protocols	IEEE802.1d STP, IEEE802.1w RSTP, Standard 802.1s MSTP, Port fast, BPDU filter, BPDU guard, TC guard, TC filter, TC protection, LOOP guard, ROOT guard
DHCP	DHCP server, DHCP client, DHCP snooping, DHCP relay, IPv6 DHCP snooping, IPv6 DHCP client, IPv6 DHCP relay
Multiple Spanning Tree Protocol (MSTP) Instances	64
Maximum Aggregation Port (AP)	Up to 128
Multicast	IGMP v1/v2/v3 snooping, IGMP SGVL/IVGL, IGMP filter, IGMP fast leave, MLD snooping v1/v2
SDN	OpenFlow 1.0, future support OpenFlow 1.3
EEE Format	Support IEEE 802.3az standard
G.8032	Support
L2 Features	MAC, EEE, ARP, VLAN, Basic QinQ, Felix QinQ, Link aggregation, Mirroring, STP, RSTP, MSTP, Broadcast storm control, IGMP v1/v2/v3 snooping, IGMP SGVL/IVGL, IGMP filter, IGMP fast leave, DHCP, Jumbo frame, RLDP, LLDP, REUP, G.8032 ERPS, Layer 2 protocol tunnel
Layer 2 Protocols	IEEE802.3, IEEE802.3u, IEEE802.3z, IEEE802.3x, IEEE802.3ad, IEEE802.1p, IEEE802.1x, IEEE802.3ab, IEEE802.1Q (GVRP), IEEE802.1d, IEEE802.1w, IEEE802.1s
Security	Binding of the IP address, MAC address, and port address; Binding of the IPv6, MAC address, and port address; Filter illegal MAC addresses; Port-based and MAC-based 802.1x; MAB; Portal and Portal 2.0 authentication; ARP-check; DAI; Restriction on the rate of ARP packets; Gateway anti-ARP spoofing; Broadcast suppression; Hierarchical management by administrators and password protection; RADIUS and TACACS+; AAA security authentication (IPv4/IPv6) in device login management; SSH and SSH V2.0; BPDU guard; IP source guard; CPP, NFPP; Port protection
Layer 3 Features	IPv4 static routing, IPv6 static routing, RIP, RIPng, OSPFv2/v3, ARP proxy, Neighbor Discovery，VRRP
Layer 3 Protocols (IPv4)	Static routing, RIP, RIPng, OSPFv2/v3
IPv4 Features	Ping, Traceroute
IPv6 Features	0-64 any length mask, ICMPv6, Neighbor Discovery, Manually configure local address, Automatically create local address, IPv6 Ping, IPv6 Tracert, IPv6 extender option head,VRRP v3
Basic IPv6 Protocols	IPv6 addressing, Neighbor Discovery (ND), IPv6 ACL, ICMPv6, IPv6 Ping, IPv6 Tracert
IPv6 Routing Protocols	Static routing, RIPng, OSPFv3
VSU (Virtual Switch Unit)	Support (up to 9 stack members，to ensure the effectiveness of the use, 4 members are recommended)
Zero Configuration	CWMP(TR069)
Reliability	RAS VSU (virtualization technology for virtualizing multiple devices into 1); GR for RIP/OSPF; ERPS (G.8032); REUP dual-link fast switching technology; RLDP (Rapid Link Detection Protocol)
Manageability	SNMPv1/v2c/v3, CLI (Telnet/Console), RMON (1, 2, 3, 9), SSH, Syslog/Debug, RSPAN/ERSPAN, NTP/SNTP, FTP, TFTP, Web, SFLOW，support cable detection and port sleep mode
Smart Temperature Control	Fanless
Other Protocols	FTP, TFTP, DNS client, DNS static
Dimensions (W x D x H) (mm)	440 × 260 × 43.6
Rack Height	1RU
Weight	≤3.5kg
MTBF	482560 hours
Lightning Protection	6KV
Power Supply	AC input: Rated voltage range: 100V to 240V AC Maximum voltage range: 90V to 264V AC Frequency: 50 to 60Hz HVDC input: Input voltage range: 192V to 290V DC
Power Consumption	≤24W
Temperature	Operating temperature: 0°C to 50°C
Temperature	Storage temperature: -40°C to 70°C
Humidity	Operating humidity: 10% to 90%RH
Humidity	Storage humidity: 5% to 95%RH
Operating Altitude	-500m to 5,000m
Safety Standards	IEC 60950-1,EN60950-1
Emission Standards	EN 300 386, EN 55032, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11
ประกัน	3 ปี
