• Two-way, high-output design
• Vented LF enclosure
• Neutrik Speakon paralleled pass-through connectors
• Two integrated handles
• Ideal for small-to-medium stages
• Signal Synchronized Transducers for woofer/tweeter alignment
• Low-distortion SMX2121 woofer with fully symmetric drive
• 1.25-inch DH3/2010A titanium HF compression driver
• Constant-directivity 90º H x 50º V horn
• Integrated 24 dB/octave crossover with HF protection
• 99 dB sensitivity, 132 dB maximum SPL
• Power handling: 500 W continuous, 2000 W peak
• Black EVCoat finish

SPECIFICATIONS

• Frequency Range (-10 dB):     55 – 20000kHz
• Flying:   No
• Minimum Impedance:   6.4Ω
• Nominal Impedance (Passive):   8Ω
• HF Transducer:  DH3
• Speaker Type:   Monitor
• Woofer Size:  12inch
• Powered or Passive:     Passive
• Frequency Response (-3 dB)¹:     70 – 20000Hz
• Max. SPL/1m (calc)²:       132dB
• Coverage (Nominal -6 dB) H:      90°
• LF Transducer:   SMX2121
• Coverage (Nominal -6 dB) V:      50°
• Power Rating:    2000W
• System Power Handling (Continuous/Program/Peak):     500Watts
• Rotatable Horn:     No
• Crossover Frequency:    1600Hz
• Enclosure Material:    Ply Wood and MDF with EVCOAT
• Available Color: Black
• Sensitivity 1 W/1 m:     99dB
• Height: 17.32″ (440mm)
• Width:  14.33″ (364mm)
• Recommended High-Pass Frequency:     60Hz
• Depth:  22.56″ (573mm)
• Internal Crossover:     Yes
• Weight Net:    43.65lbs (19.8kg)
• Family:  Tour X
• Input Connections:     Parallel Neutrik® NL4
