• High-output, high-quality sound
• Excellent pattern control for medium throw use
• Low-distortion SMX2151 woofer with fully symmetric drive
• 1.25-inch DH3/2010A titanium HF compression driver
• Rotatable Constant-directivity 60º x 40º horn
• Advanced 4th-order crossover with HF protection
• 100 dB sensitivity, 133 dB maximum SPL
• Power handling: 500 W continuous, 2000 W peak
• Lightweight trapezoidal plywood/MDF enclosure
• Pole mount for use with subwoofer or stand
• Six 3/8-inch threaded suspension points
• Black EVCoat finish

SPECIFICATIONS

• Freq. Response¹ (-3 dB) :  65 Hz – 20 kHz
• Freq. Range¹ (-10 dB)      :  45 Hz – 20 kHz
• Rec. Hipass Frequency:  45 Hz
• Axial Sensitivity :  100 dB (1W/1m)
• Max. Calculated SPL:       133 dB
• Horizontal Coverage:      90°
• Vertical Coverage:           50°
• Power Handling : 500W Continuous, 2000W Peak
• LF Transducer:   SMX2151, 15 in (381mm) Driver
• HF Transducer:  DH3, 1.25 in (32mm) Diaphragm Compression Driver
• Crossover Frequency:    1750 Hz
• Nominal Impedance:      8 Ohms
• Minimum Impedance:   6.2 Ohms
• Connectors:       (2) Neutrik Speakon NL4’s
• Enclosure Material:         Plywood and MDF with EVCoatTM
• Grille:    16 GA Steel, Black Powdercoat, with Rotatable Logo
• Dimensions (H x W x D): 18.7″ x 17.3″ x 25.8″ (475mm x 439mm x 655mm)
• Net Weight:        51.9 lbs (23.5 kg)
• Shipping Weight:      59.4 lbs (27.0 kg)
