• High-power LF supplement to TX1122 and TX1152
• High-excursion EVS-18S woofer
• 6 dB/octave low-pass filter for parallel connection without added amp
• 100 dB sensitivity, 132 dB max SPL
• Power handling: 500 W continuous, 2000 W peak
• Top-side socket for speaker pole
• Mount points (6) for optional wheel kit
• Braced plywood/MDF enclosure
• Black EVCoat finish

SPECIFICATIONS

• Frequency Range (-10 dB):       45 – 700kHz
• Flying:   No
• Minimum Impedance:   7.5Ω
• Nominal Impedance (Passive):   8Ω
• Speaker Type:   Subwoofer
• Woofer Size:      18inch
• Powered or Passive:       Passive
• Frequency Response (-3 dB)¹:     50 – 160Hz
• Max. SPL/1m (calc)²:       132dB
• LF Transducer:   18-inch EVS18S
• Power Rating:    2000W
• System Power Handling (Continuous/Program/Peak):     500//2000Watts
• Enclosure Material:         Plywood and MDF with EVCOAT
• Available Color: Black
• Sensitivity 1 W/1 m:        100dB
• Height:   30.28″ (769mm)
• Width:  20″ (508mm)
• Recommended High-Pass Frequency:     30Hz
• Internal Crossover:          Low-pass filter
• Depth:  23.27″ (591mm)
• Weight Net:       74.52lbs (33.8kg)
• Family:  Tour X
• Input Connections:    Parallel Neutrik® NL4
