Features

• 1.5 inch (3.75 cm) full-range loudspeaker units with neodymium magnets
• 170° horizontal dispersion for uniform SPL over a wide listening area
• Vertical coverage can be selected as 20°(Standard) or 40°(Wide)
• Slim design complements any interior décor
• Available in black or white
• Enclosures can be painted to match surroundings
• Wall mount bracket supplied
• Optional hardware for a wide range of installation needs

Specs

• Speaker type Full-range, Bass reflex
• Frequency range (-10dB) 77 Hz – 20 kHz *1
• Coverage area Horizontal: 170°, Vertical:20°（ +10° – -10°） (NORMAL), 40°（+10° – -30°） (WIDE)
• Components LF-HF 1.5” (3.75 cm) Cone × 24
• Power rating NOISE 110 W
• PGM 220 W
• PEAK 440 W
• Nominal impedance 8Ω
• SPL Sensitivity (1W; 1m on axis) 91 dB SPL (1 m/1 W) *1 *2
• Peak (Calculated) 117 dB SPL (1 m) *3
• I/O connectors Euroblock (2 pin) × 2 (input: +/-) Max. wire size AWG 12 (3.3 mm²)
• Protection circuit Load protection Full-range power limiting to protecting network and transducers
• Finish VXL1B-24: Black painting (approximate value: Munsell N3.0), VXL1W-24: White painting (approximate value: Munsell N9.0)
• IP-Rating Dust and water resistant : IP35
• Packaging Packaged in 1 pc
• Dimensions (W x H x D) 2.1 x 47.7 x 4.1 in. (54 x 1212 x 104 mm) – Speaker Only, 2.1 x 47.7 x 4.4 in. (54 x 1212 x 111.5 mm) – with Included Bracket
• Weight 12.1 lbs (5.5 kg) – Speaker Only
