ตู้ลำโพง ยี่ห้อ TANNOY รุ่น VXP 8
1600 Watt 8″ Dual Concentric Powered Sound Reinforcement Loudspeaker with Integrated Lab Gruppen IDEEA Class-D Amplification
Product Features
- Full range multi-purpose powered sound reinforcement loudspeaker for portable and installation applications
- 1,600 Watt power featuring Lab Gruppen IDEEA electronics Class-D amplification
- 8″ Dual Concentric full range driver for point source phase coherence
- Tightly controlled 90º dispersion for optimum coverage and forward projection
- Ideal for FOH, floor monitor, delay and stage front fill applications
- Switchable full range or high pass filter operation
- Vented and internally braced plywood enclosure
- Finished with hard wearing semi matt black paint
- Rugged powder coated perforated steel mesh grille
- Blanking plate for optional VTH pole mount
- Versatile mounting via optional custom designed hardware
- Fully balanced input and link output on Neutrik* XLR connectors
- Neutrik powerCON* for a secure locking mains power connection
- Designed and engineered in the U.K.
Specification
System
| Frequency response (Full range mode) | 80 Hz – 35 kHz ±3 dB 67 Hz – 45 kHz -10 dB |
| Frequency response (Hi-pass mode) | 120 Hz – 35 kHz ±3 dB 100 Hz – 45 kHz -10 dB |
| Nominal dispersion | 90° conical @ -6dB point |
| Directivity factor (Q) | 6.8 |
| Directivity index (DI) | 7.9 |
| Dynamic range | 106 dB |
| Maximum SPL | 125 dB peak |
| Crossover type | Passive 1.7 kHz with dynamic HF protection |
| Transducers | 200 mm (1 x 8″) constant directivity Dual Concentric™ |
Amplifier
| Maximum output power* | 1600 W |
| Type | Class-D |
| Protection | Output current limiter, clip limiter, brownout protection and recovery, thermal |
Connectors
| Input | 1 x XLR, balanced |
| Input impedance | 10 kO unbalanced, 20 kO balanced |
| Maximum input level for clip | +4.5 dBu +14.5 dBu |
| Link | 1 x XLR |
| Mains Supply | Neutrik powerCON 20A† |
Controls
| Level | Recessed potentiometer |
| Filter | Hi-pass (HPF)/ full range (FR), switchable |
| Power mode | Manual (MAN)/ auto (AUTO), switchable |
Power Supply
| Type | Switch-mode autorange power supply |
| Mains voltage | 100-240 V~, 50/60 Hz |
| Power consumption | 75 W @ 1/8 max power |
Enclosure
| Dimensions (HWD) | 389 x 281 x 276 mm (15.3 x 11.1 x 10.9″) |
| Net weight | 10.1 kg (22.2 lbs) |
| Construction | 15 mm (5/8″) plywood, vented and internally braced |
| Finish | Semi matt black paint (white optional) |
| Grille | Powder coated perforated steel |
| Flying hardware | 2 x M10 flying inserts 2 x M10 yoke bracket inserts (6 mm allen key) Blanking plate for optional VTH pole mount |
