Access Point ยี่ห้อ D-Link รุ่น DIS-200G-12SW
Features
Flexible Availability
- • Available in PoE and non-PoE models
- • Industrial model variations with wider operating temperature ranges
Robust and High-Redundancy Design
- • Fanless, passive cooling design
- • High EMC endurance
- • Built-in 6 kV surge protection on copper ports
- • Ethernet Ring Protection Switching (ERPS)
- • Dual power input for redundant power supplies
Layer 2 Features
- • IEEE 802.1Q and port-based VLAN
- • IEEE 802.1p Quality of Service (QoS)
- • STP/RSTP/MSTP
- • Port mirroring
- • Link aggregation
- • Bandwidth control
- • Broadcast storm control
- • IGMP/MLD Snooping
Advanced Features
- • Auto-Surveillance VLAN 2.0 (ASV 2.0)
Specifications
| Number of Ports | •10 x 10/100/1000BASE-T ports • 2 x SFP ports • 1 x RJ-45 Console port |
| Port Functions | • IEEE 802.3 for Ethernet • IEEE 802.3u for Fast Ethernet • IEEE 802.3ab for Gigabit Ethernet • IEEE 802.3z for Gigabit fiber • IEEE 802.3af/at Power over Ethernet (DIS-200G-12PS/DIS-200G-12PSW) • IEEE 802.3az-compliant |
| Media Interface Exchange | • Auto-MDI/MDIX adjustment for all twisted pair ports |
| Switching Capacity | • 24 Gbps |
| Maximum Forwarding Rate | • 17.85 Mpps |
| MAC Address Table Size | • Up to 8K entries |
| Transmission Method | • Store-and-forward |
| Diagnostic LEDs | • SYS • ALM • PWR1/2/3 • Link/Activity/Speed |
| Power Input | • 12 to 48 V DC terminal block dual input • 12 V DC 4-pin DIN single power input |
| Power Consumptions | • Maximum: 10.26 W • Standby: 5.94 W |
| Alarm Relay | • 1 A at 24 V |
| Heat Dissipation | • 35.01 BTU/hr |
| Weight | • 1.63 kg (3.59 lbs) |
| Dimensions | • 210 x 171.2 x 48 mm (8.27 x 6.74 x 1.89 in) |
| Ventilation | • Fanless |
| Operating Temperature | • -40 to 75 °C (-40 to 167 °F) |
| Storage Temperature | • -40 to 85 °C (-40 to 185 °F) |
| Operating Humidity | • 0% to 95% RH, non-condensing |
| Storage Humidity | • 0% to 95% RH, non-condensing |
| Material | • IP30-rated metal casing |
| Installation | • DIN rail/wall/rack mountable |
| MTBF | 219,314 hours |
| Certifications | • CE • FCC • BSMI |
| Safety | • UL60950-1 |
| EMI | • CISPR 22 • FCC Part 15B Class A |
| EMS | • EN 61000-4-2 ESD • EN 61000-4-3 RS • EN 61000-4-4 EFT • EN 61000-4-5 • EN 61000-4-6 CS • EN 61000-4-8 |
| Environmental Tests | • IEC 60068-2-27 Shock • IEC 60068-2-32 Freefall • IEC 60068-2-6 Vibration |
