Output Expanders ยี่ห้อ YAMAHA รุ่น EXo8

Specifications:

• Maximum number of simultaneously usable devices: A total of seven EXi8 and EXo8 devices. (However in a system, a total of up to20 devices, including devices such as the MTX series and XMV series, can be used.)
• Power cord length: 8.2ft
• Included items: Power cord, Euroblock plugs (3-pin, tabbed) x 8, cable ties x 8, Owner’s manual
• Sampling frequency: 48kHz/44.1kHz
• Signal delay: Less than 2.5ms
• Frequency response: 20Hz to 20kHz, -1.5dB min, 0dBtyp., +0.5dB max.
• Total harmonic distortion: Less than 0.05% (+4dBu,Gain:-6dB); less than 0.1% (+4dBu, Gain:+66dB)
• Dynamic range: 107dB (Gain:-6dB)
• Equivalent input noise (EIN): -126dBu (Gain: +66dB)
• Crosstalk / Channel separation: -100dB (@1kHz)
• Maximum cable length: [YDIF] connector: 30 meters (Cable length between devices)
• OUTPUT SIGNAL: GREEN -40dBFS
• Format NETWORK connector: 100Base-TX
• Cable specifications: [YDIF] connector: CAT5e or better Ethernet STP cable (Straight connected. All 8 pins must be connected.)
• NETWORK connector: CAT5e or better Ethernet STP cable
• Power supply voltage: US/Canada: 110V–240V 50/60Hz
• Power consumption: 25 W max.
• Heat dissipation (per hour): 21.5 kcal max.
• Operating temperature range: 0 degrees Celsius – 40 degrees Celsius
• Storage temperature range: -20 degrees Celsius – 60 degrees Celsius
• NC value: 24 (1m from the front panel)
• Dimensions: 18.9″ W x 1.73″ H x 13.8″ D
• Weight: 9.48 lbs
